Machines

Small machines built on the bench, and the experiments that got them there.

Projects

Pen Plotter A

Pen Plotter A

Working

Two steppers and a geared pen lift that draw on a 76 mm post-it pad, printed on a Bambu P1S and driven by an ESP32.

Raccoon Soaker

Raccoon Soaker

Building

A camera and a PIR guard the steps onto my deck, and an ESP32-CAM opens a 12 V water valve to soak whatever comes up them.

Experiments

Bring-ups and test rigs: one motor, one driver or one display at a time, on the way to the projects above.

Asteroid Test

Asteroid Test

Working

A tiny Spacecavator-style digger on a Nextion screen: steer through rock and collect gems with a joystick, zoom with a knob.

Servo Tester

Servo Tester

Working

Find a hobby servo's real end points and centre: a PCA9685 driver, three knobs and a display, all run by an ESP32.

Stepper Test

Stepper Test

Working

A 28BYJ-48 stepper driven through the PCA9685 and a ULN2003: milestone one of the pen plotter.
